SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

Product Categories
Shenzhen damu technology co. LTD
Contact Now

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

  • 1
  • 2
  • 3

Brand Name : DAMU

Model Number : DM-LGX-1*64 SCAPC

Certification : ISO9001,CE,FCC,ROHS

Place of Origin : CHINA

MOQ : 10pcs

Payment Terms : T/T

Supply Ability : 50000pcs/month

Delivery Time : 10-15Days

Packaging Details : 1KM-5KM/Wooden Drum, Weight: 100KG/KM, Drum Size: 78*78*68cm

Fiber type : G.657A with 0.9mm loose tube

Application : FTTH FTTB FTTX Network

Operating temperature : -40℃ to 85℃

Contact Now

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

1. Specification:

Parameter
Specification
Operating Wavelength (nm)
1260 ~ 1650
Type
1x4
1x8
1x16
2x4
2x8
2x16
1x32
2x32
1x64
Insertion Loss (dB) Max. *
<7.3
<10.5
<13.5
<7.6
<11.2
<14.5
<16.2
<18.2
<20.5
Uniformity (dB) Max.*
<0.8
<1.0
<1.5
<1.0
<1.5
<2.0
<2.0
<2.5
<2.5
PDL(dB)Max.*
<0.2
<0.2
<0.3
<0.3
<0.3
<0.4
<0.3
<0.4
<0.3
Directivity (dB)
≥55
Return Loss (dB)
UPC ≥55 APC ≥60
Operating Temperature (°C)
-5~ +75
Storage Temperature (°C)
-40 ~ +85
Fiber length
1m or custom length
Fiber Type
Corning SMF-28e fiber
Connector Type
Custom specified
Power Handling (mW)
300

Table 1 – 1×N PLC Splitter

Parameters
1×2
1×4
1×8
1×16
1×32
1×64
Operating Wavelength (nm)
1260～1650
Fiber Type
G657A or customer specified
Insertion Loss (dB)(Min/Max)
3.8/4.0
7.2/7.4
10.5/10.7
13.5/13.7
16.5/16.9
20.5/21.0
Loss Uniformity (dB)
0.6
0.6
0.8
1.2
1.5
2.5
Return Loss (dB)
55
55
55
55
55
55
Polarization Dependent Loss(dB)
0.2
0.2
0.3
0.3
0.3
0.4
Directivity (dB)
55
55
55
55
55
55
Operating Temperature (℃)
-40～+85
Storage Temperature (℃))
-40～+85
Operating Humidity
5% ~ 85% RH
Storage Humidity
5% ~ 85% RH
Device Dimension (mm) (L×W×H)
40×4×4
40×4×4
40×4×4
50×4×4
50×7×4
60×12×4
Module Dimension (mm) (L×W×H)
100×80×10
100×80×10
100×80×10
120×80×18
140×115×18
140×115×18
Mini-Module Dimension (mm) (L×W×H)
50×7×4
50×7×4
60×7×4
60×12×4
80×20×6
N/A
Table 2 – 2×N PLC Splitter
Parameters
2×2
2×4
2×8
2×16
2×32
2×64
Operating Wavelength (nm)
1260～1650
Fiber Type
G657A or customer specified
Insertion Loss (dB)(Min/Max)
3.9/4.2
7.5/7.8
11.2/11.5
14.2/14.5
17.2/17.7
21.0/21.5
Loss Uniformity (dB)
0.8
1.5
1.5
1.8
2.0
2.5
Return Loss (dB)
55
55
55
55
55
55
Polarization Dependent Loss(dB)
0.2
0.2
0.4
0.4
0.4
0.4
Directivity (dB)
55
55
55
55
55
55
Operating Temperature(℃))
-40～+85
Storage Temperature (℃))
-40～+85
Operating Humidity
5% ~ 85% RH
Storage Humidity
5% ~ 85% RH
Device Dimension (mm) (L×W×H)
40×4×4
50×4×4
50×4×4
50×7×4
60×7×4
60×12×4
Module Dimension (mm) (L×W×H)
100×80×10
100×80×10
100×80×10
120×80×18
140×115×18
140×115×18
Mini-Module Dimension (mm) (L×W×H)
60×7×4
60×7×4
60×7×4
60×12×4
80×20×6
N/A

2. Feature:

* Low Insertion loss

* Low PDL

* Compact Design

* Good channel-to-channel uniformity

* Wide Operating Wavelength: From 1260nm to 1650nm

* Wide Operating Temperature: From -40℃to 85℃

*High Reliability and Stability

3. Application:

* Low Insertion Loss.

* Fiber to home(FTTH)

* Passive Optical Networks(PON)

* Local Areal Networks(LAN)

* Fiber communication systems

4. Description:

Planar lightwave circuit (PLC) splitter is fabricated using silica optical waveguide technology. It features wide operating
wavelength range, good channel-to-channel uniformity, high reliability and small size, and is widely used in FTTX PON to realize optical signal power management.

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette typeSC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette typeSC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette typeSC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type

SC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette typeSC/APC 1 x 64 Fiber Optic PLC Splitter Mini tube Type Splitter Plc Splitter waterproof SC APC LGX box cassette type
